Manrose 120mm In-Line Shower Extractor Fan with Mounting Bracket

Product Code: ID120S
Brand: Manrose

Manrose 120mm In-Line Shower Extractor Fan with Mounting Bracket Manrose 120mm In-Line Shower Extractor Fan with Mounting Bracket
£ 37.76 ex VAT or £ 45.31 inc VAT
Select from 3 available types

Please specify your product options:

Estimated delivery: 7 - 10 working days

Manrose 120mm In-Line Fan Specification Diagram

Clear the air with the Manrose 120mm In-Line Shower Extractor Fan (ID120S). This tube fan unit is designed for remote mounting, so it’s able to offer safe ventilation in the wet areas of larger bathrooms and shower rooms without any risk of electric shock. It’s also perfect for adding extra oomph to fans that use particularly long lengths of ducting. The ID120S model features a handy mounting bracket, a long-lasting single phase induction motor, and 56% more power than its 100mm counterpart.

  • Finish: White
  • Construction: ABS
  • Complies with Building Regulations Part F1 for ventilation products
  • Can be used to boost an existing fan where longer ducting is required
  • Remote mounting of fan removes risk of electric shock
  • Suitable for the safe ventilation of bathrooms, toilets, and rooms
  • Powered by a single phase induction motor with pre-oiled bearings for a long, maintenance-free life
  • Constructed from impact-resistant ABS thermoplastic for strength and durability
  • 220-240 V - AC. 50 Hz
  • Power consumption: 15.5 W
  • Maximum pressure: 35 Pa
  • Fan speed: 2400 RPM
  • Sound volume: 41.0 dB(A)
  • Maximum operating temperature: 40 °C
  • Extraction rate: 130 m³/hr, 36 litres per second
  • Performance varies depending on the length of ducting used
  • Dimensions: please refer to diagram

Manrose 120mm In-Line Shower Extractor Fan with Mounting Bracket

Note: the lead time on this product is approximately 7 - 10 working days.

DELIVERY OPTIONS

  • Free 7 - 10 working days for UK Orders over £75.00 ex. VAT
  • £4.99 ex. VAT 7 - 10 working days for UK Orders under £75.00 ex. VAT
  • Free collection in 7 - 10 working days from our Hampton Hill (Middlesex) or Chessington (Surrey) Branches
    • We will contact you as soon as your order is ready for collection

For full delivery details, see our delivery information page. You can also add one or more products to your basket, which will calculate the cost of delivery.

We offer a 14-day money-back guarantee on all items (excluding made to order items), provided they are returned in accordance with our Terms and Conditions.

For full returns and refunds information, please see our returns and refunds information page.

Details from the manufacturer

Description

Product Fan
Qualifier Standard
Type bathrom

Dimensions

Overall Width 118 mm

Features

Air Extraction Rate m3/h 130Meter3/Hour M3/h
Motor Power 15.5 W
Mounting Ceiling
Number of Poles 2P
Use Domestic

Material & Finish

Material ABS Thermoplastic

Technical Data

Frequency 50 Hz
Maximum Sound Pressure Level 41 Db
Maximum Speed 2000 rpm
Number of Phases Single
Voltage 220 to 240 V
