Ovia Lighting Alupanel 18W 3000K White Fixed LED Downlight

Product Code: OV6218WW
Brand: Ovia Lighting

Ovia Lighting Alupanel 18W 3000K White Fixed LED Downlight Ovia Lighting Alupanel 18W 3000K White Fixed LED Downlight
£ 11.16 ex VAT or £ 13.39 inc VAT
Select from 2 available types

Please specify your product options:

Ovia’s Alupanel LED Downlight (OV6218WW) is an IP44 rated commercial fitting with a slim design for shallow ceiling voids. This model features a warm 3000K colour temperature, a 120° beam angle, and an inline LED driver prewired with a clever Flow Connector. Using just 18W to produce a 1300 lumen output, it’s sure to make an efficient addition to a wide variety of different settings.

  • Finish: White
  • Body: powder coated aluminium
  • LED colour temp: Warm White (3000K)
  • Lumens: 1300
  • Lm/W: 72
  • Beam angle: 120°
  • Watts: 18
  • CRI: >80
  • Non-dimmable
  • Inline driver
  • Prewired Flow Connector (3 pole CT 105-F Push-fit Terminals)
  • IP: 44
  • Double insulated, no earth required
  • Average lifetime: 20,000 hrs
  • Warranty: 2 years
  • Max. ceiling thickness (mm): 32
  • Cut-out (mm): 150
  • Dimensions (mm): Diameter - 170, Depth - 20.5

Ovia Lighting Alupanel 18W 3000K White Fixed LED Downlight

Cutout (mm) Dimmable? Wattage Lumens Life (Hrs)
150 No 18 1300 20,000
Colour temperature: warm white

Wondering what benefits there are to going LED? Just take a look at our helpful GO LED infographic.

IP (Ingress Protection) Rating Guide
This product is IP44 rated

Bathroom zones diagram
Zone 0 Inside the bath or shower tray. Minimum IP rating of IP67, and a maximum voltage of 12 V.
Zone 1 Directly above the bath to a height 225 cm from the floor, or the inside of shower cubicle excluding the tray. Minimum IP rating of IP65.
Zone 2 60 cm perimeter around the bath or shower to a height 225 cm from the floor. 60 cm radius around sink tap. Minimum IP rating of IP44.
Zone 3 Anything outside the other zones. No IP rating requirements.


  • Free 2 - 5 working days for UK Orders over £75.00 ex. VAT
  • £4.99 ex. VAT 2 - 5 working days for UK Orders under £75.00 ex. VAT
  • Free collection in 2 - 5 working days from our Hampton Hill (Middlesex) or Chessington (Surrey) Branches
    • We will contact you as soon as your order is ready for collection

For full delivery details, see our delivery information page. You can also add one or more products to your basket, which will calculate the cost of delivery.

We offer a 14-day money-back guarantee on all items (excluding made to order items), provided they are returned in accordance with our Terms and Conditions.

For full returns and refunds information, please see our returns and refunds information page.

Details from the manufacturer


Face Shape Circular
Lamp Type LED Fixed
Mounting Position Ceiling
Product Luminaire
Type Downlight


Cut-Out Diameter 210 mm
Depth 20.5 mm
Overall Diameter 225 mm


Adjustability Fixed
Ballast/Starter Included N
Corrosion Resistant N
Cover Included Y
Cover Type Diffuser
Dimmable N
Emergency N
Fire Rated N
Ingress Protection IP44
Lamp(s) Included? Y
LED Driver Included? Y
Microwave Sensor Included N
Mounting Type Recessed
Number of Lamps 1
Photocell Included N
PIR Included N
Self-Contained N
Vandal Resistant N
Wattage 18 W


CE Approved N
Standards BS EN 60598-1; BS EN 60598-2-2; BS EN 55015; BS EN 61000-3-2; BS EN 61000-3-3; BS EN 61547; BS EN 62031; BS EN 61347-1; BS EN 61347-2-13; BS EN 62493
UKCA Approved N
Unit Weight 0.48 kg
Warranty 3 Years

Material & Finish

Bezel/Trim Colour Signal White RAL 9003
Cover Colour Opal
Cover Material Polystyrene
Housing Colour Signal White RAL 9003
Housing Material Aluminium

Technical Data

Average Lifespan 20000 Hours
Beam Angle 120 Degrees
Colour Rendering Index >80
Colour Temperature 3000 K
Light Output 1300 Lm
Luminous Efficiency 72 Lm/W
Operating Temperature Range -5|40 Degrees C
Voltage 220-240 V
